TONHE Fan Cooling Rectifier Module, 110V DC Charging Power Supply Module

The TONHE Fan Cooling Rectifier Module is a high-performance 110V DC charging power supply module engineered for mission-critical industrial and power infrastructure applications. Built on advanced resonant switching technology, this module converts standard AC input into stable, regulated 110VDC output with exceptional efficiency (≥91%) and ultra-low ripple.
Designed with forced-air cooling, the module maintains optimal operating temperatures even under continuous full-load conditions, ensuring reliable 24/7 performance in demanding environments. Its compact form factor and lightweight construction make it an ideal space-saving solution for integrated DC power systems, battery charging systems, and industrial control cabinets.
As a core component of DC uninterruptible power systems, the TONHE 110V rectifier module provides clean, filtered DC power for battery banks and critical loads simultaneously — protecting sensitive equipment from voltage fluctuations and power interruptions.

1. High Efficiency & Energy Savings
   With ≥91% conversion efficiency, the TONHE fan cooling rectifier module minimizes energy loss and reduces operational costs. Advanced resonant switching technology lowers heat generation, extending component lifespan and reducing cooling requirements.
2. Forced-Air Cooling for Continuous Operation
   The integrated intelligent fan cooling system maintains internal heatsink temperature rise below 50°C, enabling the module to deliver full rated power continuously without derating. The fan operates at ≤55dB noise level, suitable for indoor industrial environments.
3. Comprehensive Protection Mechanisms
   The module features a full suite of protective functions to safeguard both the unit and connected equipment:
   Output Over-Voltage Protection: Auto-shutdown at 150±5VDC
   Over-Current Protection: Current limiting at 105% rated output
   Short-Circuit Protection: Hiccup-mode recovery after fault clearance
   Over-Temperature Protection: Thermal derating and shutdown
4. Compact & Lightweight Design
   Measuring just 215 × 135.2 × 51mm and weighing only 0.7kg, this module delivers high power density in a small footprint — perfect for space-constrained installations and modular rack systems.
5. Parallel Operation Capability
   Multiple modules can be paralleled for scalable power systems with ±5% current sharing imbalance, allowing flexible capacity expansion from small standalone setups to large distributed DC power architectures.
6. Wide Input Voltage Range
   Accepts 198–253VAC input (typical 220VAC), accommodating grid voltage fluctuations common in industrial and remote locations without additional regulation.

Substation & Power Grid DC Systems
The TONHE 110V fan cooling rectifier module serves as the core charging unit in substation DC operation power systems, providing reliable power for circuit breakers, relay protection devices, and control circuits. With over 290 successful projects for 220kV–500kV substations, TONHE modules are trusted by power utilities across China and export markets.
Case Example: A 220kV substation in Southeast Asia deployed 8 units of TONHE 110V DC rectifier modules in a parallel redundant configuration, achieving 99.99% uptime over 3 years of continuous operation with zero module failures.

Industrial Control & Automation
Powers PLCs, sensors, relays, contactors, and HMI panels in automation control cabinets, manufacturing lines, and process control systems. The stable 110VDC output ensures precise control signal integrity.

Telecommunications & Data Centers
Provides clean DC power for telecom base stations, data center backup systems, and communication equipment racks. Parallel operation supports N+1 redundancy for uninterrupted service.

Battery Charging Systems
Functions as an intelligent battery charger for 110V lead-acid and Ni-Cd battery banks, with adjustable output voltage (99–130VDC) to match various battery chemistries and float/equalization charging profiles.

Renewable Energy & Off-Grid Power
Integrates into solar/wind hybrid power systems and off-grid installations, converting AC from generators or grid-tie inverters into stable DC for battery storage and DC loads.

Railway & Transportation Signaling
Delivers reliable DC power for railway signaling systems, metro auxiliary power, and airport ground support equipment where power quality and reliability are critical.

Factory-Direct Quality Assurance
TONHE operates 8 advanced automated production lines with 80% automation rate and up to 99% first-pass yield. Every module undergoes double-sided potting, conformal coating, and rigorous functional, environmental, and aging testing before shipment.

Proven Industry Track Record

• Over 290 successful projects for 220kV–500kV substations
• 40%+ market share in China's DC power system module market
• Annual production capacity of 3 million modules
• Over 20 years of power electronics R&D and manufacturing experience

Global Export & Logistics Support

• MOQ: 5 pieces (sample orders available)
• Lead Time: 7 days for standard models
• Packaging: Cartons on pallets, suitable for sea/air freight
• Shipping: Worldwide via sea, air, and express (DHL/FedEx/UPS)
• Payment: T/T, L/C at sight, and other negotiated terms

Customization & Technical Support

• Custom output voltage/current configurations available
• OEM/ODM services with private labeling
• Dedicated English-speaking technical support team
• Full system-level solutions: DC distribution cabinets, monitoring units, battery systems
• Free technical consultation for system design and integration

After-Sales Warranty

• 12-month standard warranty on all modules
• Extended warranty options available
• Spare parts inventory for fast replacement
• Remote troubleshooting and on-site support (by arrangement)
• Lifetime technical consultation

•

1. Q1: What is the difference between fan cooling and natural cooling rectifier modules?
   Fan cooling modules use an integrated fan for forced-air heat dissipation, allowing higher power density and continuous full-load operation in a smaller form factor. Natural cooling (fanless) modules are silent and maintenance-free but typically larger and lower power density. Fan cooling is preferred for space-constrained installations and high-ambient-temperature environments.
2. Q2: Can multiple TONHE 110V rectifier modules be connected in parallel?
   Yes. Multiple modules support parallel operation with ±5% current sharing imbalance, enabling scalable power systems and N+1 redundancy. We recommend using modules of the same model and firmware version, and configuring them via the system monitoring unit for optimal load sharing.
3. Q3: What certifications do TONHE rectifier modules hold?
   All TONHE 110V DC rectifier modules are CE certified and manufactured under ISO9001 quality management systems. Additional certifications (UL, RoHS, etc.) can be arranged for specific export markets on request.
4. Q4: How do I adjust the output voltage for different battery charging profiles?
   The output voltage is adjustable within 99–130VDC via the module's front-panel controls or through the RS485 communication interface (on compatible models). This allows setting float charge, boost charge, and equalization voltage levels for various 110V battery systems. Consult the user manual for step-by-step configuration.
5. Q5: What is the typical lifespan of the cooling fan, and is it replaceable?
   The cooling fan is rated for 50,000+ hours of continuous operation under normal conditions. The fan is a field-replaceable component; spare fan kits are available from TONHE. For environments with high dust or humidity, we recommend periodic fan inspection and the natural-cooling series for maintenance-free operation.
